- Model
MPE-7502-ACAAG
ATX Version
ATX 12V Ver. 3.1
PFC
Active PFC
Input Voltage
100-240V
Input Current
10-6A
Input Frequency
50-60Hz
Dimensions (L x W x H)
140 x 150 x 86 mm / 5.5 x 5.9 x 3.4 inch
Fan Size
120mm
Fan Bearing
HDB
Efficiency
=90% @ Typical Load
80 PLUS Rating
80 PLUS Gold
ErP 2014 Lot 3
Yes
Operating Temperature
0-40°C
Power Good Signal
100 - 150 ms
Hold Up Time
16ms
MTBF
100,000 Hours
Protections
UVP / OVP / OPP / OTP / SCP / OCP
Regulatory
cTUVus, TUV, CE, FCC, BSMI, CCC, EAC, RCM, UKCA, RoHS2.0 / BIS, KC (Based on regions requests.)
ATX 24 Pin Connectors
1
EPS 8 Pin / 4+4 Pin Connectors
2
SATA Connectors
6
Peripheral 4 Pin Connectors
3
PCI-e 6+2 Pin Connectors
4
Warranty
5 Years
Series
G Series
80 Plus Efficiency
Gold
Modular
Non Modular
Category
500 to 750W
Form Factor
ATX
Watts
750W
