- Model
MPX-7503-AFAG-2xxx
ATX Version
ATX 12V Ver. 3.1
PFC
Active PFC
Input Voltage
100-240V
Input Current
10-5A
Input Frequency
50-60Hz
Dimensions (L x W x H)
160 x 150 x 86 mm
Fan Size
120mm
Fan Bearing
HDB
Fan Speed
2500 RPM
Efficiency
=90% @ Typical Load
80 PLUS Rating
80 PLUS Gold
ErP 2014 Lot 3
Yes
Operating Temperature
0-40°C
Power Good Signal
100 - 150 ms
Hold Up Time
=16ms at 80% Load
MTBF
100,000 Hours
Protections
OPP/ OVP/ OTP/ OCP/ SCP/ UVP/ Surge Inrush Protection
Regulatory
cTUVus, TUV, CE, FCC, BSMI, CCC, EAC, RCM, UKCA, RoHS2.0 / BIS, KC (Based on regions requests.)
ATX 24 Pin Connectors
1
EPS 4+4 Pin Connectors
1
EPS 8 Pin Connector
1
SATA Peripheral 4 Pin Connectors
6 (SATA) / 2 (Peripheral)
PCI-e 6+2 Pin Connectors
4
12V-2x6 Connectors
1
Series
MWE Gold Series
Category
Above 750W
Modular
Fully Modular
80 Plus
Gold
Form Factor
ATX
Watts
750W
