- Interface
SATA 6.0Gb/s
Form Factor
2.5-inch internal SSD
Total Capacity
480GB
NAND
NAND Flash
External DDR Cache
N/A
Sequential Read speed
Up to 550 MB/s
Sequential Write speed
Up to 480 MB/s
Random Read IOPS
up to 75k
Random Write IOPS
up to 70k
Dimension
69.85 x 7 x 100 mm
Mean time between failure (MTBF)
2M hours
Power Consumption (Active)
Average: R : 2240mW; W : 2610mW
Power Consumption (Idle)
170mW
Temperature (Operating)
0°C to 70°C
Temperature (Storage)
-40°C to 85°C
Warranty
1. Limited 3-years or 200TBW
2. Limited warranty based on 3 years or 200TBW, whichever comes first.
xTBW (Terabyte Written):Terabytes Written is the total amount of data that can be written into an SSD before it is likely to fail.
3. The "percentage of SSD life" (SMART ID: E7 or A9) in SMART page of the "GIGABYTE SSD toolbox" program will be used as the determining criteria when the number is 0 means out of warranty. (A new unused product will show the percentage of 100.)
Note
Test system configuration: configuration may vary by models; we will choose the latest platform for verification.
Performance may vary based on SSDs firmware version and system hardware configuration. Sequential performance measurements based on CrystalDiskMark and IOmeter 1.1.0.
Speeds based on internal testing. Actual performance may vary.
1GB = 1 billion bytes. Actual useable capacity may vary.-
