Model
Brand
Patriot
Series
P300
Model
P300P256GM28US
Device Type
Internal Solid State Drive (SSD)
Used For
Consumer
Details
Form Factor
M.2 2280
Capacity
256GB
Interface
PCIe Gen3 x4, NVMe 1.3
Controller
Phison E13T
Performance
Max Sequential Read
Up to 1700 MBps
Max Sequential Write
Up to 1100 MBps
4KB Random Read
Up to 290,000 IOPS
4KB Random Write
Up to 260,000 IOPS
HeatSink
No
Features
Features
The P300 is Patriot s next generation of mid-tier PCIe gen 3 x4 NVMe SSD to hit the market, offering 25% higher transfer speeds and IOPs than standard PCIe 3 x2 solutions. The compact m.2 form factor is designed for easy installation and will fit into any PC or laptop, while its low power consumption helps extend laptop battery life. The P300 is guaranteed to improve start-up, loading, and transfer times over traditional hard disk drives.
The P300 s advanced firmware offers ECC technology and end-to-end data path protection to ensure data integrity throughout the life to the drive. Advanced wear-leveling and thermal management features extend the life of the drive for maximum use.
Boost your computer s performance with quicker application loading times for a better overall experience and productivity while transferring heavy workloads without the lag.
Environmental
Power Consumption (Idle)
0.37W
Power Consumption (Active)
2.07W
Operating Temperature
0°C ~ +70°C
Dimensions Weight
Height
3.80mm
Width
22.00mm
Depth
80.00mm
Weight
9.00g-
